MRCOOL DIY® 5th Gen 55,000 BTU Multi-Zone Mini Split Condenser 230V, DIY-MULTI6-55HP230D-O
MRCOOL® DIY 5th Gen 55,000 BTU 6-Zone Multi-Zone Mini Split Condenser – 230V
Model: DIY-MULTI6-55HP230D-O
Engineered for large, multi-zone applications, the MRCOOL® DIY 5th Gen 55,000 BTU Multi-Zone Mini Split Condenser delivers up to 61,000 BTU of total connected indoor capacity. Easily cool or heat up to six separate zones using a combination of MRCOOL 5th Gen air handlers—ranging from compact 6K BTU all the way up to powerful 36K units. Designed for easy DIY installation, this unit is pre-charged with eco-friendly R-454B refrigerant and does not require special tools or HVAC licenses for setup.
Key Features
- DIY Installation: Pre-charged Quick Connect® line sets require no vacuuming—connect and go
- Smart Controls: Fully compatible with the SmartHVAC App, Amazon Alexa, and Google Assistant
- R-454B Refrigerant: Lower GWP and EPA-compliant for reduced environmental impact
- Gold Fin® Protection: Anti-corrosive coating for long-lasting outdoor performance
- DIYPRO® Cable: Armored and weatherproof—no electrical conduit needed
- Warranty Coverage: 7-Year compressor, 5-Year parts, and optional Limited Lifetime Replacement with MRCOOL® Care Program
System Specs
- Cooling Capacity: 55,000 BTU/h
- Heating Capacity: 56,000 BTU/h
- SEER2: Up to 21.5 (based on handler configuration)
- HSPF2-4: ~10.3 | HSPF2-5: ~8.2
- Power Supply: 208–230V, 60Hz, 1 Phase
- Minimum Circuit Ampacity: 34 A
- Maximum Fuse: 40 A
- Refrigerant Type: R-454B (Charge: ~160 oz)
- Line Set Sizes: 3/8" Liquid x 5/8" Gas
- Recommended Coverage: 2,000 – 2,600 sq. ft. (depending on layout and zone usage)
Compatible Air Handler Combinations (Max 61,000 BTU)
This high-capacity 6-zone condenser supports 6K, 9K, 12K, 18K, 24K, and even 36K 5th Gen air handlers. A minimum of 2 zones must be connected. Total indoor capacity must not exceed 61,000 BTU.
Sample valid combinations:
- 36K + 18K + 6K = 60K
- 24K + 12K + 12K + 9K = 57K
- 18K + 12K + 9K + 9K + 6K + 6K = 60K
- 12K + 12K + 12K + 12K + 12K = 60K
Recommended Wire Size
- Recommended: 6 AWG copper wire – supports 34A MCA and 40A fuse
- One Size Smaller (8 AWG): May be acceptable for short runs but could overheat under load—check local codes
- One Size Larger (4 AWG): Ideal for long wire runs—ensures minimal voltage drop and extra safety margin
Note: Condenser is pre-charged with R-454B refrigerant and is not backward compatible with R-410A systems. Please ensure total indoor load is within allowable limits and follow all installation guidelines.
Proudly offered by MRCOOL DIY Direct — your trusted nationwide leader for DIY HVAC products.
Specifications & Dimensions
| Specification | Details |
|---|---|
| Model Number | DIY-MULTI6-55HP230D-O |
| Cooling Capacity | 55,000 BTU/h |
| Heating Capacity | 55,000 BTU/h |
| Recommended Coverage Area | 2,800 – 3,200 sq. ft. |
| Maximum Connected Capacity | Up to 61,000 BTU |
| SEER2 (Estimated) | 17.5 – 18.0 (depending on configuration) |
| HSPF2-4 (Estimated) | 8.5 – 9.0 |
| HSPF2-5 (Estimated) | 6.5 – 7.0 |
| Power Supply | 208–230V, 60Hz, 1 Phase |
| Minimum Circuit Ampacity | 48 A (est.) |
| Maximum Fuse | 50 A (est.) |
| Refrigerant Type | R-454B |
| Refrigerant Charge | ~120 oz (est.) |
| Line Set Sizes | 3/8" Liquid x 5/8" Gas |
| Net Dimensions (WxDxH) | Approx. 42.91" x 19.88" x 37.01" |
| Net Weight | Approx. 185 – 195 lbs |
| Recommended Wire Size | 6 AWG (recommended for 48A load) |
| One Size Smaller (Risk) | 8 AWG – May overheat or fail to meet code on longer runs |
| One Size Larger (Benefit) | 4 AWG – Ideal for long wire runs and additional safety margin |
