MRCOOL® Signature Series Single Stage 96% AFUE 5 Ton 135,000 BTU Multi-Position Multi-Speed Gas Furnace - MGM96SE135D5XA

For optimal heating performance, choose the MRCOOL® Signature Series Single Stage 96% AFUE 5 Ton 135,000 BTU Multi-Position Multi-Speed Gas Furnace. It can be installed in an upflow or horizontal configuration and is both energy efficient and quiet running. The unit’s multi-speed high efficiency blower motor aids in the unit’s 96% AFUE. For enhanced cooling SEER ratings, apply this unit with properly matched cooling equipment. The aluminized steel primary heat exchanger with crimped non-welded construction aids in this unit’s durable build and finish. For optimal operation, the furnace features aluminized steel inshot burners and a durable silicon nitride ignitor for smooth ignition. The single stage gas valve helps to deliver heating to your home quickly and effectively. The removable floor base for bottom return air, zero step horizontal conversion, and left or right utility connections all help to make installation of the furnace easy and time saving. It features a compact 33 inch design and offers standardized widths for easy coil fit. It can be easily vented with PVC pipe and is design certified for direct and non-direct vent applications. An optional LP kit is available as well for a liquid propane conversion. Thanks to the easily removable slide out blower design, maintenance is a breeze. MRCOOL® backs this product with a lifetime heat exchanger warranty and a 10-year parts warranty.

Specifications:

BRAND	MRCOOL
MODEL	MGM96SE135D5XA
SERIES	Signature Multi Position 96% AFUE Furnace
UNIT TYPE	Gas Furnace
AFUE	96%
CFM	2000
TONNAGE	5 Ton
FUEL TYPE	Gas
BTU INPUT	132000
BTU OUTPUT	127000
VOLTAGE	120V
PHASE	1
CYCLE	60Hz
MAX FUSE BREAKER	15
FULL LOAD	10.9
GAS CONNECTION SIZE	1/2 in
AHRI CERTIFIED	Yes
NET DEPTH	29 in
NET HEIGHT	33 in
NET WIDTH	24.5 in
GROSS WEIGHT	174 lbs
